An easy to install wireless camera and monitor kit that provides a crystal clear picture as you reverse your vehicle. The 5" colour screen simply plugs into a cigarette lighter socket and mounts to your car's dash or windscreen using the suction cup bracket. The waterproof HD camera connects to your reversing lights for operation and mounts above your number plate using the short or long mounting brackets provided. The wireless digital signal from the camera is encrypted and ensures a more stable interference-free picture. Other features include infrared illumination to improve visibility in the dark, reversing guidelines, and 12-24VDC operation, making it also suitable for trucks.
Display Screen
| Screen Type |
Flat Panel Screen (LCD) |
| Screen Backlit |
LED Backlit |
| Horizontal Screen Resolution |
|
| Vertical Screen Resolution |
480Pixel |
| Screen Width |
132.5mm |
| Screen Height |
89.5mm |
Wireless Transmission
| Transmission frequency |
2.4GHz |
Ingress Protection Rating
| IP rating for |
Camera |
| IP Rating |
IP65 |
| Dust/Particle Ingress Protection |
6 - Dust tight, no ingress of dust |
| Liquid/Moisture Ingress Protection |
5 - Water jets |
Reversing Cameras & Monitors
| General Type |
rearview camera |
| Cameras Included |
1pc |
| Camera View Angle |
110° |
| Camera Resolution (V) |
550Pixel |
Vehicle or Vessel Powered
| Required Voltage |
9V-30V |
| Vehicle Connection |
Cigarette Lighter, Bare Leads |
| Item Connection |
Barrel Plug |
Product Dimensions
| Dimension details |
Camera |
| Depth |
25mm |
| Height |
25mm |
| Width |
27mm |
Packaged Dimensions
| Packaged Volume |
2.464128l |
| Packaged Weight |
0.61kg |
| Packaged Length |
21.6cm |
| Packaged Width |
12.4cm |
| Packaged Height |
9.2cm |
