| Dimensions (L x W x H) |
650W–850W: 140 x 150 x 86mm
1000W–1200W: 160 x 150 x 86mm |
| 80 Plus Rating |
GOLD |
| ATX Version |
ATX 3.0 |
| Protections |
OCP, OVP, OPP, OTP, UVP, SCP, NLO, SIP |
| Certifications |
CE, CB, FCC(IC), TUV, cTUVus, TUV S-Mark, NOM, BSMI, UKCA, EAC, CCC, RCM |
| PFC |
> 0.99 |
| Input Voltage |
100–240V |
| Input Frequency |
47Hz–63Hz (all models) |
| Operating Temperature |
50°C |
| Fan Bearing |
FDB (Fluid Dynamic Bearing) |
| Fan Speed |
2400 RPM |
| MTBF |
100K hours at full load |
| Warranty |
10 Years |
| |
|
| Fan Size by Wattage |
|
| Wattage |
Fan Size |
| 650W–850W |
120mm FDB Fan |
| 1000W–1200W |
135mm FDB Fan |
| |
|
| |
|
| Input Current by Wattage |
|
| Wattage |
Input Current |
| 1200W |
15A |
| 1000W |
13A |
| 850W |
12A |
| 750W |
10A |
| 650W |
10A |
| |
|
| DC Output Voltage |
+5V | +3.3V | +12V | -12V | +5Vsb |
