Description
An IP65 rared weatherproof alternate rocker switch for use in marine and auto switch panels where the switch may be exposed to the elements. Ideal for use on industrial machinery, pumps etc. Illuminated red with 12V DC led. Contacts rated for 6A @ 250V DC, however, this switch is ideally used in low voltage situations.
- Switch type: SPST alternate
- Contact rating: 6A @ 250V AC
- Neon: Red 12VDC
- Panel thickness: 2.5mm max.
- Electrical life: 10,000 cycles
- Mechanical life: 100,000 cycles
- Contact resistance: 50mΩ max.
- Insulation resistance: >100MΩ
- Dielectric strength: 1500V
