Designed to control 100V line speaker systems these attenuators have been enclosed in a ABS Flange Mount Enclosure. They feature 11 position switches for fine adjustment of sound level. All circuitry is housed on a PCB with screw terminals for easy...
These controllers can be configured as either five single inputs to five outputs or one input to five outputs. Each zone has a 100W load capacity, with a total panel capacity of 500W. The 100W model has ten position plus off. The input and outputs are...
This Attenuator Volume Control 5 Zone Evac 40W / 100V Line can be configured as either five single inputs to five outputs or one input to five outputs. Each zone has a 40W load capacity, with a total panel capacity of 200W. This model has six settings...
Features two line inputs and one mic input, each with its own level control. The mic input can be configured for either balanced or unbalanced operation. All inputs are mixed to a single line level output. It can be powered from either a single rail...
Balanced 600 Ohm 3 pin female XLR to unbalanced 10K Ohm 2 x RCA with level control. +10dB max signal gain. Steps up input signal by factor of 16, ie 20mV in = 320mV out.
Dimension Drawing
This Evacuation controller is easy to operate and is designed around industry standard building emergency alert/evacuate requirements. When connected to a paging system amplifier, building occupants can be alerted and/or evacuated in the
event of an...
This High power commercial grade 10” subwoofer is ideal for providing additional low end response to foreground music and hi-fi applications. Built in 100V line transformer makes it suitable for integration with commercial systems in fashion boutiques,...
These 6 input compact Class-D design amplifiers offer multi source mixing including 4 mic and 2 AUX inputs plus USB/SD card/FM tuner audio playback and Bluetooth streaming functionality. They are an all in one amplifier and audio source housed in just a...
These 6 input compact Class-D design amplifiers offer multi source mixing including 4 mic and 2 AUX inputs plus USB/SD card/FM tuner audio playback and Bluetooth streaming functionality. They are an all in one amplifier and audio source housed in just a...
These compact 1RU rack mount amplifiers are suitable for both stand alone PA system use, or as zone amplifiers in larger systems requiring local inputs. All models operate on 240V AC or 24V DC for battery backup operation.
The input consists of a 3-pin...
These compact 1RU rack mount amplifiers are suitable for both stand alone PA system use, or as zone amplifiers in larger systems requiring local inputs. All models operate on 240V ac or 24V dc for battery backup operation. The input consists of a 3-pin...
The A 1715 is an MP3 based message player, housed in a convenient DIN rail housing. It has four independent contacts for remote triggering of the four available MP3 audio files. These files can be a recorded message, a music track or any audio whatsoever...
These compact modules are designed to remotely alter the volume of any low level signal source feeding any amplifier or mixer remotely, via RS 232 or RS 485 serial control. They will interface with the "Redback Touch" wallplate or any other 3rd party...
A high quality commercial grade passive 8” subwoofer for use with either 100V line PA amplifiers or low impedance 4 - 8 Ohm amplifiers. This sub provides additional low end response to foreground music and hi-fi applications. Built in 100V line...
This microphone/line receiver hub is designed to accept audio from up to four A 4931 zone wallplates or other Redback UTP transmitter. The A 4931 wallplate accepts either a microphone or line input and converts the signal to a balanced high level output...
This unit is designed as an isolation unit to prevent hum loops in audio systems. Balanced 10kΩ to balanced 10kΩ 3 pin male XLR with ground. lift and capacitive coupling switch.
Dimension Drawing
This unit can be used for balancing a line level signal (converting a 10kΩ unbalanced signal to 600Ω balanced) and as an isolation unit to prevent hum loops in audio systems.
Dimension Drawing
