Run from your battery to distribution blocks and then 2 AWG, 4 AWG or 8 AWG to your amplifiers or other power equipment for seriously high current applications.
• Conductor material: OFC
• Insulation material: PVC
Rated to 240A Peak, 200A Constant
Red AWG 0 cable Cat No. WH3092
Black AWG 0 cable Cat No. WH3094
Wire and Cable
| Wire Category | Hook up / power |
|---|
| AWG | 0.0 |
|---|
| Outer Diameter | 15.0 mm |
|---|
| Conductor Overall Diameter | 8.7 mm |
|---|
| Number of Conductor Strands | 3.0 pc |
|---|
| Individual Conductor Strand Diameter | 0.12 mm |
|---|
| Core Material | Tin Plated Copper |
|---|
| Resistance per Linear Metre | 0.35 mΩ |
|---|
| Retail Sales Unit | Metre |
|---|
| Roll Length | 25.0 m |
|---|
| Strand Weave Configuration | 7 x 7 x 81 |
|---|
| Number of Conductor Cores | 1.0 pc |
|---|
| Cross Sectional Area | 44.9 mm² |
|---|
Product colour
Operating Temperature and Humidity
| Operating Temperature | -10.0°C-90.0°C |
|---|
DC Current Rating
General Purpose Cable
| Wire Category | Mega High Power |
|---|
| AWG | 0.0 |
|---|
| Outer Diameter | 15.0mm |
|---|
| Conductor Overall Diameter | 8.7mm |
|---|
| Number of Conductor Strands | 4655.0 |
|---|
| Core Material | Tinned Copper |
|---|
| Resistance per Linear Metre | 0.35 mΩ |
|---|
| Retail Sales Unit | Metre |
|---|
| Roll Length | 25m |
|---|
| Insulation Material | PVC |
|---|
Product Dimensions
Packaged Dimensions
| Packaged Dimensions | 100.0cm(Length) x 1.6cm(Width) x 1.6cm(Height) |
|---|
