A compact DC UPS designed to connect inline with your ordinary 12VDC mains power adaptor. In the case of a power outage, the internal battery will keep your equipment operating for longer. Three interchangeable DC connectors are supplied to suit a range of devices such as a modem, network switch, router, video device, surveillance systems or lights. An integrated smart charger ensures the internal 18650 Li-ion batteries are charged, and adjusts the charge current based on the current draw to the device you are powering. The rated output is 2.5A at 12V but 3A can be provided for a short time. Four status LEDs indicate the UPS charge status, and safety features include over-charge, over-discharge, over-current, and short-circuit.
Features:
Features:
- 2.5A Output
- DC Power
- Built-in rechargeable Li-ion battery
- Integrated smart charger
- LED status indicators
DC Connectors (mm):
Input: 5.5OD x 2.1ID - Center Tip Positive
Output: 5.5OD x 2.5ID - Center Tip Positive
Adaptors (mm):
5.5OD/2.5ID Male to 5.5OD/2.1ID Female - Center Tip Positive
3.5OD/1.35ID Male to 5.5OD/2.5ID Female - Center Tip Positive
5.5OD/2.1ID Male to 3.5OD/1.35ID Female - Center Tip Positive
DC Current Rating
| DC current rating | 2.5 A |
|---|---|
| DC Current Surge Rating | 3.0 A |
Product Dimensions
| Length | 138.0 mm |
|---|---|
| Width | 60.0 mm |
| Height | 24.0 mm |
| Weight | 260.0 g |
Classified as dangerous goods
| DG UN Number | 3481.0 |
|---|---|
| DG Class | 9.0 |
| DG Pack Group | II - Medium Danger |
| DG Hazardous Chemical Code | 4W |
| DG Ship Name | 3481 - Lithium Ion Batteries Packed In Equipment |
| Battery Watt Hour Rating (Required for Lithium Batteries) | 7.4 Wh |
Packaged Dimensions
| Packaged Dimensions | 19.7cm(Length) x 15.5cm(Width) x 3.3cm(Height) |
|---|
