DIP style - will plug into 16 pin IC socket. Low profile mini 12V 2 coil latching relay. Highly sensitive - 180mW nominal power consumption.
Relay
| Latching | true |
|---|
| Contact format | DPDT |
|---|
| AC Contact Voltage | 250.0V,250.0V |
|---|
| DC Contact Voltage | 220.0V,220.0V |
|---|
| Nominal Voltage | 12.0 V |
|---|
| Input | DC |
|---|
Power Rating
Power Source Details
| AC Current Draw | 1.0 A |
|---|
| DC Current Draw | 2.0 A |
|---|
| AC Voltage | 250.0 V |
|---|
| DC Voltage | 12.0 V |
|---|
Product Dimensions
| Width | 20.0 mm |
|---|
| Height | 10.0 mm |
|---|
| Depth | 10.0 mm |
|---|
Packaged Dimensions
| Packaged Dimensions | 2.0cm(Length) x 1.0cm(Width) x 1.3cm(Height) |
|---|
