• Rated to DC 15A Peak, 11A Constant
• Stranding: 26 x 0.3mm
• PVC insulation
• Max temperature 80°C
Available seperately
Black WH-3075
Wire and Cable
| Wire Category | Hook up / power |
|---|---|
| AWG | 16.0 |
| Conductor Overall Diameter | 3.3 mm |
| Core Material | Tin Plated Copper |
| Retail Sales Unit | Metre |
| Roll Length | 100.0 m |
Product colour
| Colour | Red |
|---|
DC Current Rating
| DC current rating | 15.0 A |
|---|
General Purpose Cable
| Wire Category | DC Power Cable |
|---|---|
| AWG | 18.0 |
| Outer Diameter | 2.8mm |
| Conductor Overall Diameter | 1.2mm |
| Number of Conductor Strands | 26.0 |
| Core Material | Tinned Copper |
| Resistance per Linear Metre | 0.021Ω |
| Retail Sales Unit | Metre |
| Roll Length | 100m |
| Insulation Material | PVC |
Product Dimensions
| Cable length | 100.0 m |
|---|
Packaged Dimensions
| Packaged Dimensions | 100.0cm(Length) x 0.28cm(Width) x 0.28cm(Height) |
|---|
