An ideal way to distribute high current paths. An 8mm stud provides for incoming cable and distribution is via 16 screw terminals with 6mm cable entry holes. Solid brass with high-quality plastic bridge mounts. Rated for 100A, suitable for high-power car audio power distribution or multiple earth links.
DC Current Rating
Terminal Barriers & Strips
| Type | Busbar |
|---|
| Device | 16-Way 100A |
|---|
| Length | 150mm |
|---|
| Number of Contacts | 16.0 |
|---|
| Terminal Spacing | 5.08mm |
|---|
| Attachment Method | Screw |
|---|
| Body Material | Polyamide |
|---|
| Contact Material | Phos. Bronze |
|---|
| AC Voltage Rating | 300V |
|---|
| AC Current Rating | 15A |
|---|
| Insulation Dielectric Voltage Rating | 2000V AC |
|---|
| Insulation Resistance | 500MΩ |
|---|
Product Dimensions
| Length | 112.0 mm |
|---|
| Width | 18.0 mm |
|---|
| Height | 12.0 mm |
|---|
Packaged Dimensions
| Packaged Dimensions | 18.3cm(Length) x 11.7cm(Width) x 3.5cm(Height) |
|---|
