| Specification | SPATIUM M452 PCIe 4.0 NVMe M.2 |
| Capacity | 1TB |
| Controller | PHISON E29T |
| Flash Memory | 3D NAND |
| Form Factor | M.2 2280 |
| Interface | PCIe Gen4 x4, NVMe 1.4 (2CH) |
| Compatibility | PCIe Gen4 / Gen3 / Gen2 / Gen1 |
| Dimensions (L × W × H) | 80.00 × 22.00 × 2.15 mm |
| Sequential Read (Up to) | 3,600 MB/s |
| Sequential Write (Up to) | 3,100 MB/s |
| Random Read 4KB (Up to) | 500,000 IOPS |
| Random Write 4KB (Up to) | 750,000 IOPS |
| Idle Power (PS3) | 50 mW |
| Low Power (L1.2) | 5 mW |
| Operating Temperature | 0°C – 70°C |
| Storage Temperature | -40°C – 85°C |
| Terabytes Written (TBW) | 300 TB |
| Mean Time Between Failures (MTBF) | Up to 1,500,000 Hours |
| Warranty | 5-Year Limited Warranty, or until the maximum TBW is reached (whichever comes first) |
