Straight forward installation and wiring, with just four connections - everything else is pre-wired! Then all you need to do is connect your various peripheral devices. Switches are rated at 20A for a 12V system (10A for 24V) up to a maximum 45A per panel. The LED illumination is powered separately, so you can run it through a switch or dimmer too.
Features:
Features:
- Easy installation
- High quality switches
- Blue LED illumination
Specifications:
Switch Rating: 12VDC @ 20A, 24VDC @ 10A
Panel Rating: 45A
Toggle Switches
| Switch Type | Switch Panel |
|---|---|
| Poles / Contacts | 2.0 pole |
| Throws / Positions | 2.0 pos |
| Switch Function | ON-OFF |
| Contact Resistance | 50mΩ |
| Insulation Resistance | 100MΩ |
| Dielectric Strength | 1500V |
| Mechanism Material | Plastic/Metal |
| DC Voltage Rating | 12.0V |
| DC Current Rating | 20.0A |
| Cycle Life | 10000.0 |
| Actuator Length | 25.0mm |
| Actuator Width | 25.0mm |
Product Dimensions
| Width | 70.0 mm |
|---|---|
| Height | 69.0 mm |
| Weight | 105.0 g |
Packaged Dimensions
| Packaged Dimensions | 8.0cm(Length) x 10.0cm(Width) x 8.5cm(Height) |
|---|
