In line or PCB mounted RS206 silicon bridge rectifier.
Active Diode
| Diode Type | Bridge rectifier |
|---|---|
| Diode Composition | Silicon |
| Diode forward voltage drop | 1.1 V |
| Peak Reverse Voltage | 600.0 V |
| Diode maximum current | 2.0 A |
| Diode package | bridge rectifier (vertical or horizontal round or square) |
Packaged Dimensions
| Packaged Dimensions | 1.4cm(Length) x 0.5cm(Width) x 2.8cm(Height) |
|---|
