This Plug has a Multatude of uses for Audio, Video and Computer Applications.
The Audio application generally use two common wiring standards.
Some Example of a Wiring Configuration
From Apple (CTIA) & Computer Headsets
Tip (Left), Ring1 (Right), Ring 2 (Ground), Sleeve (Mic)
From Nokia / Samsung (OMTP)
Tip (Left), Ring1 (Right), Ring 2 (Mic), Sleeve (Ground)
AV - Cables is wired for Audio Left + Right and Video
Camcorder AV
Tip (Left), Ring1 (Viideo), Ring 2 (Ground), Sleeve (Right)
Apple AV
Tip (Left), Ring1 (Right), Ring 2 (Ground), Sleeve (Video)
For Computer to USB (Android / IOS Devices)
Tip (Power) +5V),
Ring1 (Data D-),
Ring 2 (Data D+),
Sleeve (Ground 0V)
Plug or Socket
| Pack Quantity | 1.0 pc |
|---|---|
| Device | Plug |
| Plug or Socket Type | 3.5mm 4 Pole |
| Contacts / Pins | 1.0 pc |
| Case Material | Plastic |
| Contact Material | Gold Plated |
Packaged Dimensions
| Packaged Dimensions | 1.0cm(Length) x 1.0cm(Width) x 4.6cm(Height) |
|---|
