This waterproof IP68 3 pin connector features a screwless termination and locking connection to mating connectors (see P8650 for male line versions). This makes it ideal for applications that are often disconnected and reconnected, but is also suitable for static installation. It features a high level of moisture and dust resistance at IP68 with flame retardant plastics. 19mm mounting hole.
Features:
Secure and easy to mate twist lock connection.
IP68 weatheproof rating.
Ideal for industrial, mining and agricultural use.
Mates with P8650 male line plug.
Up to 16A at 450V rated.
Specifications:
Number of Poles: 3Pin
Rated Voltage: 450V
Rated Current: 16A
Wire Section: 0.5-2.5mm2
Outer Cable Diameter: 5-9mm, 9-12mm
Mounting Hole Size: 19mm
Temperature Range: -40℃-+105℃
IP Code: IP68
Housing Material: PA66
Contact/Terminal Materials: Copper Alloy
3 Pin 16A Locking Female Chassis IP68 Waterproof Plug
$29.00
