Hirschmann C16-1 Series or similar connectors offer 4 or 7 way (3 and 6 with plus a P.E. - or pre-engaging - earth contact). The mating parts securely screw together to form environmental protection to IP-67. For further technical information see specifications. A quality industry-standard connector.
Features
- Electrical: 3 Pole + PE
- Contact Resistance: ≤5mohm
- Suitable for panel mount.
Environmental:
- Temperature range: -40°C to + 100°C
- Housing: Polyamide 6.6
- Strain Relief: Screw clamp/Ring & Gland Nut (9mm)
Plug or Socket
| Pack Quantity | 1.0 pc |
|---|
| Device | Plug |
|---|
| Plug or Socket Type | C16-1 Series |
|---|
| Contacts / Pins | 3.0 pc |
|---|
| Attachment Method | Solder Tag |
|---|
| Case Material | Plastic |
|---|
| Insulation resistance | 10.0 GΩ |
|---|
| Contact Material | Plated Metal |
|---|
| Cable Entry Diameter | 0.9mm,0.9mm |
|---|
AC Voltage Rating
DC Voltage Rating
DC Current Rating
Ingress Protection Rating
| IP Rating certificate | true |
|---|
| IP Rating | IP67 |
|---|
Packaged Dimensions
| Packaged Dimensions | 4.0cm(Length) x 3.0cm(Width) x 3.0cm(Height) |
|---|
