Features:
- Input 1.6 watts
- Impeller Plastic, fibreglass filled
- Housing Plastic, fibreglass filled.
12V powered cooling fans to help ventilate enclosures or confined spaces in the caravan or RV.
TEK203 60mm
Speed: 4,000 RPM
Air volume: 0.57m3 per min
Dimensions: 60(L) x 60(W) x 25(D)mm
TEK212 120mm
Speed: 3,000 RPM
Air volume: 2.5m3 per min
Dimensions: 120(L) x 120(W) x 25(D)mm
Ventilation Fans
| type of fan | Axial |
|---|
| fan air volume cubic metres | 0.57 m³/min |
|---|
| fan RPM | 4000.0 RPM |
|---|
| fan noise | 30.0 dB |
|---|
| fan bearing type | Sleeve |
|---|
| fan housing material | Plastic |
|---|
| fan impeller material | Plastic |
|---|
| Fan Operational Life at 25°C | 60000.0 hr |
|---|
| fan number of wires | 2.0 pc |
|---|
| fan connector type | Flyleads |
|---|
| fan air volume cubic feet | 20.0 ft³/min |
|---|
| Tachometer Output | false |
|---|
Power from Plugpack
| DC Plugpack Voltage | 12.0 V |
|---|
| DC Current Draw | 130.0 mA |
|---|
Mains powered
Product Dimensions
| Length | 60.0 mm |
|---|
| Width | 60.0 mm |
|---|
| Depth | 25.4 mm |
|---|
Packaged Dimensions
| Packaged Dimensions | 6.4cm(Length) x 6.8cm(Width) x 3.0cm(Height) |
|---|
