Provides 8 additional ports to an internet router, firewall, or a standalone network. All ports support 10/100Mbps and feature auto-MDI/MDIX, which means it will work fine with both straight-through and crossover network cables. Plug-and-play installation, and low power consumption from a compact unit.
Features:
Features:
- Auto-MDI/MDIX port
- MAC address auto-learning and auto-aging
- Half and Full Duplex
Specifications:
MAC Address Table: 1K entries per device
Protocol: CSMA/CD
Forwarding performance: 1.2Mpps
Backplane Bandwidth: 1.6Gbps
Transmission Method: Store-and-Forward
Network Infrastructure Hardware
| Type of Hardware | Switch |
|---|---|
| Speed of Transmission | 100.0 Mb/s |
| Communication standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
Power from Plugpack
| DC Plugpack Voltage | 5.0V,0.0V |
|---|---|
| DC Current Draw | 500.0mA,0.0mA |
| Suitable PSU Included | true |
| PSU Powers | Main Product |
LAN Details
| LAN Standard | 100 Base T |
|---|---|
| LAN Port Type | RJ45 |
| Number of LAN Ports | 8.0 ports |
Product Dimensions
| Width | 139.0 mm |
|---|---|
| Height | 25.0 mm |
| Depth | 76.0 mm |
| Weight | 155.0 g |
Packaged Dimensions
| Packaged Dimensions | 14.7cm(Length) x 8.8cm(Width) x 9.2cm(Height) |
|---|
