An easy way to add audio effects or music to your next project. The compact board measures just 47mmm long
Features:
- 23mm diameter speaker
- 2 watt amplifier
- Volume control trimpot
- Powered by 5 volts
Note: Before use, please adjust the sound volume to minimum to avoid damaging the speaker.
DC Current Rating
| DC current rating | 500.0 mA |
|---|
DC Voltage Rating
Product Dimensions
| Length | 47.0 mm |
|---|
| Width | 30.0 mm |
|---|
| Height | 13.0 mm |
|---|
| Weight | 8.4 g |
|---|
Audio Amplifier
| Type of Amplifier | IC Module |
|---|
| Number of Channels | 1.0 ch |
|---|
| Power Per Channel into Low Impedence (WRMS) | 2.0 W |
|---|
Speaker Specifications
| Speaker Type | Hobby Speaker |
|---|
| RMS Power Rating | 0.15 W |
|---|
| Frequency Response | 800.0Hz-4.0Hz |
|---|
| Sensitivity (SPL@1W, 1m) | 80.0 dB<sub>SPL</sub> |
|---|
| Nominal Size | 23.0 mm |
|---|
Packaged Dimensions
| Packaged Dimensions | 12.5cm(Length) x 7.4cm(Width) x 1.4cm(Height) |
|---|
