With back-EMF and over-temperature protection, it is ideally suited to drive two-motor robot kits. An on-board 5V regulator can also be used to power your project.
Features:
• Screw Terminals for easy connections
• LEDs show power and output status
• Requires six digital pins
• 4 mounting holes
Warning: Always use an exterrnal 5V logic supply when using more than 12V dricing voltage
Arduino Modules
| Required Supply Voltage | 5.0V,35.0V |
|---|
| Sensor IC | L298N (ST) |
|---|
Product Dimensions
| Width | 69.0 mm |
|---|
| Height | 36.0 mm |
|---|
| Depth | 56.0 mm |
|---|
Packaged Dimensions
| Packaged Dimensions | 8.4cm(Length) x 5.8cm(Width) x 3.2cm(Height) |
|---|
