Details
ASUS Prime series motherboards are expertly engineered to unleash the full potential of 14thGen Intel®Core™ Processors. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, PRIME B760M-A WIFI-CSM provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features. This platform delivers the power and connectivity that advanced AI PC applications demand.
ASUS Corporate Stable Model
ASUS Corporate Stable Model (CSM) is a commercial program designed to provide stable and reliable motherboards. Offering up to 36-month product lifecycle support and 6-month end-of-life notice to allow sufficient lead times for your organization to get ready for product transitions. Each purchase of an ASUS CSM motherboard comes with ASUS Control Center Express - server-grade IT management software.
ASUS Control Center Express
ASUS Control Center Express is an integrated IT monitoring and management software designed to deploy faster, simplify IT operations and improve productivity with comprehensive control and user-friendly functions. ASUS Control Center Express is compatible with over 100 ASUS motherboards to provide a high-quality, TCO-optimized solution for your business needs.
Optimize IT endpoint management
Designed to assist IT staff in monitoring and controlling devices within their corporate networks, and facilitate inventory checking in multiple locations remotely
Automate IT maintenance
Allows IT staff to schedule automatic updates of the latest BIOS, software and utilities to specific or all devices at off-peak times, enhancing system stability and IT operational flexibility
Securely manage all of endpoints
Securely manage endpoint configuration, portable storage access and PC software applications by enabling them to create grouping rules on individual devices
Specifications
| Audio Channels | 7.1 |
| Onboard Video | CPU Dependent Video |
| Package Contents |
|
| Brand Compatibility | Intel |
| Form Factor | Micro ATX |
| Width | 244 mm |
| Depth | 244 mm |
| Number of PCI Express x16 Slots | 3 |
| PCI Express Standard | PCI Express 4.0 |
| Total Number of PCI Express Slots | 3 |
| Total Number of Expansion Slots | 3 |
| Number of SATA Interfaces | 4 |
| Total Number of Onboard USB Ports | 10 |
| Number of Onboard USB 2.0 Ports | 5 |
| Number of M.2 Interfaces | 2 |
| RAID Levels | 10 |
| 5 | |
| 1 | |
| 0 | |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| Bluetooth | Yes |
| Gigabit Ethernet | Yes |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11 a/b/g/n/ac/ax |
| Bluetooth Standard | Bluetooth 5.2 |
| 2.5Gigabit Ethernet | Yes |
| S/PDIF | Yes |
| HDMI | Yes |
| HDMI Version | 2.1 |
| Number of Network (RJ-45) Ports | 1 |
| DisplayPort | Yes |
| Total Number of USB Ports | 6 |
| Number of USB 3.2 Gen 2 Type-A Ports | 2 |
| Product Type | Desktop Motherboard |
| Manufacturer Part Number | PRIME B760M-A WIFI-CSM |
| Manufacturer Website Address | http://www.asus.com/au |
| Manufacturer | ASUS Computer International |
| Product Model | B760M-A WIFI-CSM |
| Product Name | Prime B760M-A WIFI-CSM Desktop Motherboard |
| Product Line | Prime |
| Brand Name | Asus |
| Processor Supported | Pentium Gold |
| Core | |
| Celeron | |
| Total Processor Supported | 1 |
| Processor Socket | Socket LGA-1700 |
| Chipset Manufacturer | Intel |
| Chipset Model | B760 |
| Processor Generation Supported | 13th Gen |
| 12th Gen | |
| 14th Gen | |
| Maximum Memory Supported | 128 GB |
| Memory Technology | DDR5 SDRAM |
| Number of Memory Slots | 4 |
| Memory Form Factor | UDIMM |
| DIMM | |
| Memory Speed Supported | 6000 MHz |
| 5800 MHz | |
| 5600 MHz | |
| 4800 MHz | |
| 6200 MHz | |
| 7200 MHz | |
| 5000 MHz | |
| 5200 MHz | |
| 5400 MHz | |
| 6400 MHz | |
| 6600 MHz | |
| 6800 MHz | |
| 7000 MHz |
3 Year
