Compact size, high current, variable output and fan cooling make these the ideal power supply for your bench. They are protected against thermal overload and short circuit and will display a warning LED in the event of a fault condition. Current and voltage are displayed on separate backlit analogue meters.
Two models available:
MP-3800 Compact Switchmode Lab Power Supply 0 - 24V
Current output: Max 17A, 6A continuous at 24VDC - refer User Manual specifications
Product Dimensions
| Width | 148.0 mm |
|---|
| Height | 62.0 mm |
|---|
| Depth | 162.0 mm |
|---|
Power Supply Units
| Type of Power Supply | Laboratory |
|---|
| Regulation Type | SMPS |
|---|
| Voltage Display | true |
|---|
| Current Display | true |
|---|
| Output Connection | Banana 4mm (standard),Binding Post Terminals |
|---|
| Ripple Voltage | 9.0 mV |
|---|
| Number of Outputs | 1.0 pc |
|---|
Mains powered
| Rated for AU Mains | true |
|---|
| Rated for US Mains | false |
|---|
| Auto-select mains voltage | false |
|---|
| Mains Item connection | Standard IEC320 (C13/C14) |
|---|
| Mains lead included | true |
|---|
| Mains Voltage Range | 230.0 V |
|---|
| Frequency | 50.0 Hz |
|---|
AC Voltage Rating
| AC Voltage rating | 230.0 V |
|---|
| AC Frequency | 50.0 Hz |
|---|
DC Current Rating
Packaged Dimensions
| Packaged Dimensions | 20.5cm(Length) x 19.5cm(Width) x 7.0cm(Height) |
|---|
