Details
| · Fully modular |
| · ATX 3.1 Compliant |
| · Supports PCIe 5.1 |
| · Native 12V-2x6 connector |
| · 100% Japanese 105°C-rated electrolytic capacitors |
CORSAIR RMx Series Fully Modular Low-Noise Power Supplies deliver quiet, dependable power with 80 PLUS Gold efficiency to your PC. Fully modular cables make PC builds easy, as you connect only the cables your system requires. Compliant with the ATX 3.1 power standard from Intel®, RMx PSUs have the connections needed to power today’s demanding PC hardware including a native 12V-2x6 connector. 100% Japanese 105°C-rated electrolytic capacitors deliver fantastic electrical performance, while a 140mm FDB fan provides low noise cooling. Backed by a ten-year warranty, RMx PSUs are the gold standard for many years to come.
RMx SERIES
THE GOLD STANDARD OF POWER SUPPLIES Watch VideoQUIET, DEPENDABLE, EFFICIENT
Our best-selling PSU, updated. This fully modular, low noise, Cybenetics Gold-certified power supply is ATX 3.1 compliant and ideal for delivering dependable power to today's top-performing PCs.
50°C CONTINUOUS OPERATING TEMPERATUREEnsures reliable power for your PC, even under high-stress conditions.
105°C-RATED CAPACITORSBuilt with 100% Industrial-grade, 105°C-rated Japanese electrolytic capacitors for unwavering power and reliability.
ATX 3.1 CERTIFIED
Be confident your PSU supports the latest sleep and hibernate modes and modern CPU and GPU requirements. ATX 3.1 compliance ensures full compatibility with modern components and power states.
CLEAN CABLING, EVERY TIMEFULLY MODULAR CONNECTORS
Connect only what you need using sleek embossed cables with low-profile combs to make installations a breeze.
Native 12V-2x6 GPU cable included for use with modern graphics cards such as the NVIDIA® GeForce RTX™ 40 Series.
140mm LOW-NOISE FAN
A fluid dynamic bearing fan with magnetic dome structure keeps noise to a minimum, with Zero RPM mode to eliminate fan noise completely at low to medium loads.
ENGAGE MANUAL CONTROLSMANUAL FAN OVERRIDE KNOB
Want to get more air through the PSU or to exhaust some heat from your case? You can override the Zero RPM Mode and low-noise profile of the RMx Series with our manual fan override knob, increasing fan speed and airflow.
TEN-YEAR WARRANTYWORLD-CLASS SUPPORT
CORSAIR's award-winning service means you can enjoy your gear worry-free.
RM850x POWER TABLE
| MODEL | RPS0197 | |
|---|---|---|
| Part No. | 75-005876 | |
| AC Input Rating | ||
| AC Input | 100 – 240V | |
| Input Current | 10A - 5A | |
| Frequency | 47~63Hz | |
| Max Load | Max Output | |
| +3.3V | 20A | 150W |
| +5V | 20A | |
| +12V | 70.8A | 849.6W |
| +5Vsb | 3A | 15W |
| Total Power | 850W |
Specifications
| Model Number | CP-9020270-AU |
| Cybenetics Efficiency | Gold |
| Cybenetics Noise | A |
| ATX Connector | 1 |
| ATX12V Version | 3.1 |
| Cable Type | Type 4 |
| Continuous Power W | 850 Watts |
| EPS Connector | 2 |
| MTBF Hours | 100,000 hours |
| SATA Connector | 8 |
| PATA Connector | 3 |
| Modern Standby | Yes |
| Dimensions | 160 x 150 x 86 |
| Modular | Fully |
| PCIe Connector | 3 |
| Zero RPM Mode | Yes |
| Weight | 3.28 |
| Warranty | 10 Years |
| Package Contents |
RM850x Power Supply DC Cable Kit Power Cord Mounting Screws Cable Ties |
10 Year
