A 8-32V voltmeter with clear and precise reading. The gauge is useful to monitor battery or generator status and spot anomalies easily. Features double layered anti-fogging glass. Draws almost no power, so putting volt sense wire close to battery less critical.
MGG210 Black - Red digits over black background
MGG212 White - Red digits over white background
- 60mm overall bezel Dia.
- 2" (52mm) panel cut out
- IP67 ingress protection (Front Side)
- IP65 ingress protection (Back Side)
- Stainless steel bezel with double layered anti-fogging glass
- Background illumination (Red)
- 12/24V
- Pre-terminated connecting plug supplied
- Dropping resistors supplied for 24V panel
- Simple calibration set-up with clear instructions supplied
- Extra technical tips for electrically noisy installations
*Panel thickness 0.8mm-25mm (reverse mounting the plastic lock nut achieves this.)
*Requires 55mm clearnace behind mounting panel
Packaged Dimensions
| Packaged Dimensions | 8.5cm(Length) x 7.5cm(Width) x 7.5cm(Height) |
|---|
