This 1.5 inch OLED display features 128 x 128 RGB pixels to provide an attractive colour display for your next project. This OLED uses the SSD1351 driver chip, which manages the display. You can talk to the driver chip using 4-wire write-only SPI (clock, data, chip select, data/command, and an optional reset pin).
Features:
- RGB 128 x 128 pixels
- SSD1351 chipset
- Passive Matrix Display
- 262,144 Colours
- 1/128 Drive Duty
Display Screen
| Screen Type | Flat Panel Screen (OLED) |
|---|
| Screen Width | 26.8 mm |
|---|
| Screen Height | 26.8 mm |
|---|
| Aspect Ratio | 1:1 |
|---|
| LCD Screen Technology | Thin Film Transistor (TFT) |
|---|
Arduino Modules
| Required Supply Voltage | 5.0V,5.0V |
|---|
Product Dimensions
| Length | 34.0 mm |
|---|
| Width | 34.0 mm |
|---|
| Depth | 2.0 mm |
|---|
| Weight | 3.8 g |
|---|
Carton 1 Dimensions
| Width | 26.8 mm |
|---|
| Height | 26.8 mm |
|---|
| Dimensions details | Display Area |
|---|
Packaged Dimensions
| Packaged Dimensions | 7.4cm(Length) x 3.6cm(Width) x 2.1cm(Height) |
|---|
