This versatile board has 2 x 5V servo ports connected to the Arduino's high-resolution dedicated timer to ensure jitter-free operation. It is also capable of driving up to 4 bi-directional DC motors with individual 8-bit speed selection, or up to 2 stepper motors with single/two/interleaved steppings.
Features:
• 4 H-Bridges: per bridges provides 0.6A (1.2A peak current) with thermal protection
• 2 external terminal power interface
Arduino Modules
| Required Supply Voltage | 5.0V,16.0V |
|---|
Product Dimensions
| Length | 70.0 mm |
|---|
| Width | 53.0 mm |
|---|
| Height | 20.0 mm |
|---|
Packaged Dimensions
| Packaged Dimensions | 12.9cm(Length) x 10.9cm(Width) x 2.6cm(Height) |
|---|
