IP65 rated, illuminated switch for automotive and marine applications. Illuminates one side red and one side green.
Rocker Switches
| Switch Type | Rocker |
|---|
| Switch Function | On-Off-On |
|---|
| Mechanism Material | Plastic |
|---|
| Switch Connection | Spade Terminals |
|---|
| Switch Colour Coded | Red |
|---|
| Nominal Voltage | 12V |
|---|
| Illumination Colour | Red/Green |
|---|
| LED Connection | Spade Terminals |
|---|
| LED Type | 5mm LED |
|---|
| Illumination Position | Internal |
|---|
Ingress Protection Rating
| Dust/Particle Ingress Protection | 6 - Dust tight, no ingress of dust |
|---|
| Liquid/Moisture Ingress Protection | 5 - Water jets |
|---|
Product Dimensions
| Length | 48.0 mm |
|---|
| Width | 24.0 mm |
|---|
| Height | 27.0 mm |
|---|
Electromechanical Switch
| Switch Type | Rocker |
|---|
| Poles / Contacts | 1.0 pole |
|---|
| Throws / Positions | 2.0 pos |
|---|
| Switch Function | Locking On/Off |
|---|
| Centre Off | true |
|---|
| Mechanism Material | Plastic |
|---|
| Switch Connection | Spade Terminals |
|---|
| Switch Colour Coded | Red |
|---|
| Pole Throw Type | SPDT |
|---|
DC Voltage Rating
DC Current Rating
In-built Illumination
| Illumination Colour | Green |
|---|
| Nominal Voltage | 12.0V-12.0V |
|---|
| Connection | Spade Terminals |
|---|
| Type | 5mm Standard LED |
|---|
Packaged Dimensions
| Packaged Dimensions | 7.6cm(Length) x 7.2cm(Width) x 2.7cm(Height) |
|---|
