This is an excellent true RMS multimeter that features a large, easily read display and carries an IP67 environmental rating. This means the multimeter is waterproof and will not be damaged if accidentally dropped into water or left out in the rain. The meter has data hold and relative measurement capabilities, and is housed in a robust, double moulded case.
Includes leads, soft carry case and user manual.
Features:
• IP67 waterproof
• True RMS
• Auto power-off
• Backlight
• Data hold & relative function
• Diode test
• Autoranging
• Audible continuity
• 10A current range
• Double moulded case
• Display 4000 count
• Security Class Cat IV 600V
• Basic DCV accuracy 0.500%
• Ave/RMS True RMS
• Input impedance 10M
• Special features IP67, data-hold, relative measurement, backlight
Digital Multi-Meter
| Count Maximum Reading | 4.0 count |
|---|
Meter
| Meter Input Impedence | 10.0 Ω |
|---|
| Input Protection Fuse | 500.0mA,10.0mA |
|---|
| Casing | Plastic |
|---|
Meter Display
Power from disposable battery
| Size / Shape | 9V |
|---|
| Battery quantity | 1.0 pc |
|---|
| Compartment location | Internal / In-built |
|---|
| How is battery compartment kept closed | Clip and Screw |
|---|
Meter Safety Rating
| Safety Category | Cat IV |
|---|
| Safety Rating Max Volt | 600.0 V |
|---|
Meter Probes
| Probe rating voltage | 600.0 V |
|---|
| Probe safety rating | Cat IV |
|---|
Measures Voltage AC
| AC Voltage Ranges | 400.0mV,4.0V,40.0V,400.0V,1.0V |
|---|
| AC Voltage Accuracy | 0.8 % |
|---|
Measures Voltage DC
| DC Voltage Ranges | 400.0mV,4.0V,40.0V,400.0V,1.0V |
|---|
| DC Voltage Accuracy | 0.5 % |
|---|
Measures Current AC
| AC Current Ranges | 4.0mA,40.0mA,400.0mA,10.0A |
|---|
| AC Current Accuracy | 1.8 % |
|---|
Measures Current DC
| DC Current Ranges | 4.0mA,40.0mA,400.0mA,10.0A |
|---|
| DC Current Accuracy | 1.2 % |
|---|
Measures Resistance
| Resistance Ranges | 400.0Ω,4.0kΩ,40.0kΩ,400.0kΩ,40.0MΩ |
|---|
| Resistance Accuracy | 0.8 % |
|---|
Measures Capacitance
| Capacitance Ranges | 4.0nF,40.0nF,4.0µF,40.0µF,100.0µF |
|---|
| Capacitance Accuracy | 3.0 % |
|---|
Measures Frequency
| Frequency Ranges | 4.0kHz,40.0kHz,400.0kHz,4.0MHz,10.0MHz |
|---|
| Frequency Accuracy | 1.5 % |
|---|
Measures Continuity
| Continuity indicator | Needle |
|---|
Ingress Protection Rating
| Dust/Particle Ingress Protection | 6 - Dust tight, no ingress of dust |
|---|
| Liquid/Moisture Ingress Protection | 7 - Immersion up to 1m |
|---|
Product Dimensions
| Length | 182.0 mm |
|---|
| Width | 82.0 mm |
|---|
| Depth | 55.0 mm |
|---|
Packaged Dimensions
| Packaged Dimensions | 23.3cm(Length) x 13.2cm(Width) x 8.0cm(Height) |
|---|
