This Arduino compatible development board is a smaller version of the popular Leonardo. It measures just 23 x 20mm and is a great choice when you need a low cost and compact Arduino project. The power and three of its' analogue and digital pins go to large gold-plated tabs, making them suitable to connect alligator clips or for sewing onto clothing with conductive thread (sold separately). The board features a 32u4 ATMEL processor with a 16MHz clock, 10 x pins, consisting of 4 x power, 3 x analogue I/O pins, and 3 x digital I/O pins. 500mA output on VCC pins
Specifications:
• 16MHz Clock Speed
• 32kB Flash Memory (4kB used by bootloader)
• 1kB EEPROM Memory
• Power in 5VDC via Power In Pins
• Power Out 5VDC via Power Out Pins
• Digital Output x 3
• Analogue Output x 3
USB Powered
| USB Voltage Input | 5.0V,5.0V |
|---|
Computer Specifications
| RAM | 32.0 kB |
|---|
| Flash Memory | 1.0 kB |
|---|
Arduino Boards
| Microcontroller | ATmega32u4 |
|---|
| Program memory | 32.0 KB |
|---|
Product Dimensions
| Width | 23.0 mm |
|---|
| Height | 4.0 mm |
|---|
| Depth | 20.0 mm |
|---|
Packaged Dimensions
| Packaged Dimensions | 10.0cm(Length) x 10.0cm(Width) x 1.5cm(Height) |
|---|
