Adjustable version of ZV1642 (12V fixed) switchmode boost regulator in 5-pin TO-220 package. Can output up to 50V from 3.5V to 40V input (maximum theoretical voltage gain is x10). A small number of external components are needed for operation (see datasheet).
Active voltage regulator
| Regulator package | TO-220 |
|---|
| Regulator polarity | Positive |
|---|
| Regulator maximum current | 3.0 A |
|---|
| Regulator output voltage | 3.5V,50.0V |
|---|
| Regulator type | LM2577-ADJ |
|---|
Active Component
| active mount type | Through Hole |
|---|
| active connector type | Solder Legs |
|---|
Packaged Dimensions
| Packaged Dimensions | 3.0cm(Length) x 1.0cm(Width) x 1.0cm(Height) |
|---|
