This fun retro project is based on the ATMEGA32U4 chip, driven by an Arduino Leonardo, and features a 1.3 inch OLED screen and volume control. It can be powered by connecting a USB cable or from 2 x AAA batteries (sold separately).
Components:
- 1 x Console circuit board
- 6 x White/blue caps
- 4 x M2*6mm round-headed screws
- 4 x M2*10mm round-headed screws
- 4 x M2.0*11mm dual-pass copper pillars
- 4 x White insulating column ABS
- 1 x 3*83mm black screw driver
- 1 x Acrylic case
- 1 x USB cable
- 1 x Instruction booklet
Product Dimensions
| Width | 65.0 mm |
|---|
| Height | 100.0 mm |
|---|
| Depth | 28.0 mm |
|---|
| Weight | 71.0 g |
|---|
Power from disposable battery
| Size / Shape | AAA |
|---|
| Battery quantity | 2.0 pc |
|---|
| Batteries included | false |
|---|
| Batteries can be replaced by user | true |
|---|
| Type | Alkaline |
|---|
Packaged Dimensions
| Packaged Dimensions | 11.8cm(Length) x 9.7cm(Width) x 4.6cm(Height) |
|---|
