12V/24V/36V/48V 60A SMART SOLAR CONTROLLER
- 12V/24V/48V auto-select battery voltage. 150V max. PV open circuit voltage, 60A rated charge current. 860W @12V or 1720W @24V or 3440 @48V maximum PV power. Two sets of MC4 connectors. An ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers when light intensity is changing continuously. Innovative BlueSolar algorithm will always maximise energy harvest by locking in the optimum MPP. No cooling fan. Maximum efficiency exceeds 98%. Fully programmable charge algorithm and eight pre-programmed algorithms, selectable with a rotary switch. Offers over-temperature, short circuit and reverse polarity protection. Includes built-in Bluetooth for set-up, monitor, update and synchronise SmartSolar Charge Controllers. Optional external battery voltage and temperature sensing via Bluetooth by pairing with BMV-712 smart battery monitor. Recovers low voltage batteries. It will initiate charging even if the battery has been discharged to zero volts. Dimensions: 215x250x95mm. IP43 ingress protection rated.
