| Product Name | MAG PANO M110R / WHITE |
| Case Form Factor | Mini Tower |
| Motherboard Form Factor Support | Micro-ATX, Mini-ITX |
| I/O Ports | 1 x USB 20Gbps (Type-C) 1 x Mic In / Audio Out 1 x USB 5Gbps (Type-A) 1 x LED Switch Button 1 x Power Button |
| Drive Mount Support | 1 x 2.5” 1 x 3.5” 2 x 2.5” / 3.5” Combo |
| Expansion Slots | 5 |
| Maximum GPU Length | 410 mm / 16.14 inches |
| Maximum CPU Cooler Height | 165 mm / 6.50 inches |
| Power Supply Support | ATX |
| Maximum PSU Length | 200 mm / 7.87 inches |
| Fan Size Support | Top: 3 x 120 mm / 2 x 140 mm Front: N/A Rear: 1 x 120 mm Side: 2 x 120 mm / 2 x 140 mm Bottom: 3 x 120 mm |
| Pre-installed Fan Type | Side: 2 x 140 mm ARGB Fan (Reverse Blades Fan) Rear: 1 x 120 mm ARGB Fan |
| Radiator Size Support | Top: 120 / 140 / 240 / 280 / 360 mm Front: N/A Rear: 120 mm Side: 120 / 240 mm Bottom: N/A |
| Dimensions (DxWxH) | 434 × 225 × 444 mm / 17.09 × 8.86 × 17.48 inches |
| Net Weight | 5.7 kg / 12.57 lbs |
| Gross Weight | 8.0 kg / 17.64 lbs |
