Operating in the 2.4GHz frequency band, the nRF24L01+PA+LNA is a wireless transceiver module designed for long-range communication while maintaining low power consumption. This makes it ideal for applications such as wireless sensor networks, remote robotic controls, and other wireless communication projects.
Featuring an onboard power amplifier (PA) and a low-noise amplifier (LNA), the module enhances both signal strength and sensitivity, significantly extending its communication range. The PA provides up to 20 dBm of output power, while the LNA offers a gain of up to 10 dB, ensuring reliable data transmission even in noisy environments. With support for data rates up to 2Mbps, this wireless module can achieve a maximum range of approximately 1100 meters in open space with a clear line of sight.
For simple powering and interfacing with other devices, see Z6563 adapter board.
Specifications:
Operating frequency: 2400MHz ~ 2524MHz
Modulation: GMSK
Receiver sensitivity: -95dbm
Operating voltage: 2.7V ~ 3.6V
Max current consumption when transmitting data: 115mA
Max current consumption when receiving data: 45mA
Gain of PA: 20 dB
Gain of LNA: 10 dB
Supply Voltage: Standard
Dissipation Module: Standard
Operating Temperature: -40 to 85°C
