| Basic | TDP | 310W |
| CPU Socket | Intel LGA: 115X / 1200 / 1700 / 1851 | |
| CPU Socket | AMD: AM4 / AM5 | |
| Tube | 400 × ID Φ6.5 × OD Φ12.5mm | |
| Fan Quantity | 3 | |
| Net Weight | 1618g | |
| Radiator | Dimension | 456 × 138.5 × 27mm (L × W × H) |
| Material | Aluminium | |
| Pump | Dimension | 95 × 98 × 102mm (L × W × H) |
| Speed | 3100 ± 10% RPM | |
| Noise | ≤27dB(A) | |
| Connector | 3-Pin | |
| Rated Voltage | 12VDC | |
| Rated Current | 0.3A | |
| Power Consumption | 3.6W | |
| Bearing | Ceramic Bearing | |
| Motor | Three-phase Six-pole Motor | |
| MTBF | 30,000 Hours | |
| Fan | Dimension | 120 × 120 × 25mm (L × W × H) |
| Bearing Type | Hydraulic Bearing | |
| Speed | 500–2400 ± 10% RPM500–2000 ± 10% RPM (with speed-control cable) | |
| Air Flow (MAX) | 88CFM73CFM (with speed-control cable) | |
| Air Pressure (MAX) | 5.7mmH₂O4.3mmH₂O (with speed-control cable) | |
| Noise | ≤36dB(A)≤29dB(A) (with speed-control cable) | |
| Rated Voltage | 12VDC | |
| Rated Current | 0.26A | |
| Power Consumption | 3.12W | |
| Connector | 4-Pin PWM | |
| Pump Display | Size | 3.95 inch |
| Type | IPS | |
| Resolution | 480 × 480px | |
| Pump LED | Type | ARGB |
| Connector | 3-Pin | |
| Rated Voltage | 5VDC | |
| Rated Current | — | |
| Power Consumption | — | |
| Fan LED | Type | ARGB |
| Connector | 3-Pin | |
| Rated Voltage | 5VDC | |
| Rated Current | 0.24A | |
| Power Consumption | 1.2W |
