General
USB 3.0 Extender Cable
As USB 3.0 devices are getting popular, the demand for extending the distance covered by USB devices is growing notably. LC7206 USB 3.0 Extender Cable not only extends the distance for the USB devices up to 5 meters, but also delivers a throughput of up to 5 Gbps when used in conjunction with a USB 3.0 host and device-an astounding increase that is ten times the capability of USB 2.0.
In addition to its robust speed and transfer rate, the LC7206 also provides a durable, high quality connection that harnesses the full capability of the USB 3.0 standard; at the same time, it is backwards compatible with USB 2.0 and 1.1 to ensure reliable data communication. With LC7206, extending the distance of your USB 3.0 deviceis quick and easy, making it an ideal addition to your USBsystem setups.
Features
- Extends the distance of one USB device up to 5 m (16ft)
- USB 3.0, 2.0 and 1.1 compatible
- Built-in USB 3.0 Hub IC-fully supports hot swapping for a variety of USB 1.1/2.0/3.0 devices.
- Supports USB super-speed (5 Gbps)
- Plug and play-no additional software installation required
- Multiplatform support-Windows and Mac
- Non-powered *
Contents:
- 1x LC7206 USB 3.0 Extender Cable
Specifications
| Connectors | Upstream Port | 1 x USB Type A Male |
| Downstream Port | 1 x USB Type A Female | |
| USB Specifi cation | 3.0 / 2.0 / 1.1 for Super / High / Full or Low speed | |
| Cable Length | 5 m | |
| Data Transfer Rate | Up to 5 Gbps | |
| Environment | Operating Temp. | 0-40°C |
| Storage Temp. | -20-60°C | |
| Humidity | 0-80% RH, Non-condensing | |
| Physical Properties | Housing | Plastic |
| Weight | 230g | |
