The Redback A 4395A is a 500 Watt Mixer amplifier for installations requiring a high power zone amplifier. Ideally suited for use in shopping centres, pedestrian precincts, public transport facilities and convention centres.
The amplifier has two audio inputs, with input 1 either a balanced XLR Mic input or dual RCA line input, and input 2 a dual RCA. There is also a music input on the front of the amplifier for connection of portable devices. This input when connected, over-rides the rear input 2 audio source and is adjusted via the volume 2 level control.
A VOX circuit with front panel sensitivity adjustment, allows input 1 to mute input 2. Phantom power (15 volts) is available at the 3 pin Mic XLR on input 1, and both RCA inputs 1 and 2 have adjustable input sensitives. The amplifier has a host of protection circuitry including over current, over voltage and short circuit protection.
Features
Robust design incorporating latest Mosfet technology
Very Low noise and distortion
70V, 100V and 4-16Ω outputs
240V AC or 24V DC operation
24V DC @ 1 Amp output for external devices
300mA battery trickle charge
Adjustable input level sensitivities
Bass and Treble controls
Phantom power on microphone input (XLR Input 1)
Multi stage thermally cued fan cooling
Output Peak Limited
Thermal Overload protected
Signal Presence Indicators
Fault Indicators
Power Status Indicators
Rack Mountable (suits 19 inch racks)
100% developed, designed & assembled in Australia.
Since 1974 Redback PA products have been manufactured in Perth, Western Australia by Altronics. With over 50 years experience in the commercial audio industry, we offer consultants, installers and end users reliable products of high build quality with local product support. Read more about our Australian Made products
Backed by an industry leading 10 Year Manufacturer Warranty.
Our Redback products have a long tried and tested history of bulletproof reliability. Altronics offers a 10 Year Warranty on all Australian Made Redback products. Our local in-house service department has all the know how to answer technical queries and provide timely service. Read more about our industry leading warranty.
