The TRIAC is a three terminal semiconductor device for controlling current. It gains it's name from the term TRIode for Alternating Current.
It is effectivly a development of the SCR or thyristor, but unlike the thyristor which is only able to conduct in one direction, the TRIAC is a bidirectional device.
Type: SC141D
active SCR
| Is it an SCR or a triac | Triac |
|---|---|
| SCR voltage max | 400.0 V |
| SCR IE | 6.0 mA |
| SCR VF | 2.0 V |
| SCR IG (uA) | 50.0 µA |
| SCR VG (V) | 2.5 V |
| SCR hold In | 50.0 mA |
Packaged Dimensions
| Packaged Dimensions | 3.0cm(Length) x 1.0cm(Width) x 1.0cm(Height) |
|---|
