Ultra slim solid state relay for switching AC loads up to 250V using a DC control voltage.
• Control Voltage: 9.6-14.4VDC
• Maximum Control Current: 15mA
• Load Voltage: 50-250VAC
• Maximum Load Current: 2A
• Dimensions: 24(L)x21(H)x6.5(D)mm
Relay
| Device Type | Solid State Relay |
|---|
| Pickup Voltage | 9.6 V |
|---|
| Dropout Voltage | 1.0 V |
|---|
| Contact format | SPST |
|---|
| AC Contact Voltage | 50.0V,250.0V |
|---|
| AC Switching Current (Closing) | 0.0 A |
|---|
| Nominal Voltage | 12.0 V |
|---|
| Input | DC |
|---|
Power Source Details
| DC Current Draw | 15.0 mA |
|---|
| DC Voltage | 9.6V,14.4V |
|---|
| Item connection | PCB Pins |
|---|
Product Dimensions
Packaged Dimensions
| Packaged Dimensions | 2.5cm(Length) x 0.7cm(Width) x 2.5cm(Height) |
|---|
