A small magnetic reed switch designed for surface mounting. Fitted with screw terminals. SPDT for N.O. and N.C. applications. Includes matching magnet. Approx. 55 x 12 x 11mm size.
Specifications:
Dimensions: 55 x 12 x 11mm
Material: ABS
Colour: White
Sensing Gap: 15-25mm
Output: COM (NO & NC)
Current/Voltage/Power: 0.2A/30V/3W
Installation: Screw mount
Connection: Terminals block wiring
Parameters:
Contact from: Form C
Voltage (V-max): 30V
Current (V-max): 0.2A
Rating (V-max): 3A
Contact Resistance (max): 100mΩ
Operate time (max): 0.5ms
Operating Frequency (max): 400Hz
Pull in Value: 08-35 AT
Contact capacitance (max): 0.5pF
