Specifications
Weight dimensions
| Width | 150 mm |
|---|---|
| Height | 86 mm |
| Depth | 140 mm |
Power
| AC input frequency | 50/60 Hz |
|---|---|
| Combined power 5V | 110 W |
| Max output current 5Vsb | 2.5 A |
| Max output current -12V | 0.5 A |
| Max output current 5V | 17 A |
| Max output current 12V | 48 A |
| Max output current 3.3V | 23 A |
| Combined power 5Vsb | 12.5 W |
| Combined power -12V | 6 W |
| Combined power 12V | 576 W |
| Combined power 3.3V | 110 W |
| Power Factor Correction PFC type | Active |
| Total power | 650 W |
| Peak power | 80 W |
| AC input voltage | 100 - 240 V |
Ports interfaces
| SATA power cable length | 150,500 mm |
|---|---|
| Peripheral Molex power cable length | 150,500 mm |
| PCI Express power connectors 62 pin | 2 |
| PCI Express power cable length | 50 cm |
| CPU power connector 44 pin | Y |
| CPU power cable length | 1 mm |
| PCI Express connector | Y |
| Motherboard power cable length | 60 cm |
| Motherboard power connector | 24-pin ATX |
| Number of SATA power connectors | 6 |
Internal IO
| Peripheral Molex power connectors 4-pin | 4 |
|---|
Keyboard
| Onoff switch | Y |
|---|
Endurance
| Mean time between failures MTBF | 100000 h |
|---|
Other features
| Cabling type | Non-Modular |
|---|
Operational conditions
| Operating temperature T-T | 5 - 40 °C |
|---|---|
| Storage temperature T-T | -40 - 55 °C |
| Operating relative humidity H-H | 20 - 85% |
| Storage relative humidity H-H | 10 - 95% |
Design
| Product colour | Black |
|---|---|
| Cooling type | Active |
| Number of fans | 1 fan(s) |
Performance
| Purpose | PC |
|---|---|
| EPS version | 2.92 |
| ATX version | 2.3 |
| Power supply unit PSU form factor | ATX |
| 80 PLUS certification | 80 PLUS Bronze |
Features
| Fan diameter | 12 cm |
|---|---|
| Input current | 12 A |
Packaging content
| Cables included | CPU, PCIe, Peripheral (Molex), Peripheral (Molex) to SATA 3.3, SATA |
|---|
5 Year
