Specifications
| WARRANTY INFORMATION | |
|---|---|
| Warranty | 1 Year |
| HARDWARE | |
| Bus Type | USB 3.1 Gen 1 |
| Chipset ID | RTL8153 |
| Industry Standards | IEEE 802.3, 802.3u and 802.3ab |
| Interface | RJ45 (Gigabit Ethernet) |
| Ports | 1 |
| PERFORMANCE | |
| Auto MDIX | Yes |
| Compatible Networks | 10/100/1000 Mbps |
| Full Duplex Support | Yes |
| Maximum Cable Length | 0.6 in [1.5 cm] |
| Maximum Data Transfer Rate | 5Gbps |
| Type and Rate | USB 3.0 – 5 Gbit/s |
| CONNECTOR(S) | |
| Connector Type(s) | 1 – USB Type-C (24 pin) USB 3.0 Male |
| External Ports | 1 – RJ-45 Female |
| SOFTWARE | |
| OS Compatibility | Windows® XP, Vista, 7, 8, 8.1, 10, 11 Windows Server® 2003, 2008 R2, 2012, 2016 Mac OS X® 10.8 to 13.2 Linux Kernel 2.6.25 to 4.4.x LTS Versions only |
| SPECIAL NOTES / REQUIREMENTS | |
| System and Cable Requirements | Available USB Type-C port |
| POWER | |
| Power Source | USB-Powered |
| ENVIRONMENTAL | |
| Humidity | 20% ~ 90% RH |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | -55°C to 125°C (-67°F to 257°F) |
| PHYSICAL CHARACTERISTICS | |
| Color | Black |
| Form Factor | Attached Cable |
| WHAT’S IN THE BOX | |
| Included in Package | 1 – VL-RJ45-C |
