An essential gauge to monitor your engine. Accurately displays water temperature with reading range of 40 - 120°. Works with MGG510 water temperature sender.
Specifications:
• Measurement range: 40-120°C
• Face and bezel colour: Black
• Cutout diameter: 52mm
• Overall bezel diameter: 60mm
• Front side IP Rating: IP67
• Read side IP Rating: IP65
• Background illumination: Red
• Operating voltage: 12/24V (supplied with dropping resistor for 24V use)
• Pre-terminated connecting plug supplied
• Simple calibration set-up with clear instructions supplied
• Extra technical tips for electrically noisy installations
• Panel thickness 0.8mm-25mm (reverse mounting the plastic lock nut achieves this.)
• Requires 55mm clearnace behind mounting panel
Packaged Dimensions
| Packaged Dimensions | 8.8cm(Length) x 7.8cm(Width) x 8.2cm(Height) |
|---|
