High power DPDT relay suitable for switching loads up to 10A. Designed to suit the SY-4064 DIN rail mounting cradle it can also be mounted directly into a PCB. Operational life: 20 million cycles
Relay
| Device Type | Cradle Mounting Relay |
|---|
| Coil Resistance | 650.0 Ω |
|---|
| Coil Current | 37.0 mA |
|---|
| Contact format | DPDT |
|---|
| Operation Time | 25.0 ms |
|---|
| AC Contact Voltage | 240.0V,240.0V |
|---|
| DC Contact Voltage | 24.0V,24.0V |
|---|
| AC Switching Current (Opening) | 10.0 A |
|---|
| DC Switching Current (Opening) | 10.0 A |
|---|
| Nominal Voltage | 24.0 V |
|---|
| Input | DC |
|---|
Power Source Details
| DC Current Draw | 37.0 mA |
|---|
| DC Voltage | 24.0 V |
|---|
Product Dimensions
| Length | 35.0 mm |
|---|
| Width | 21.2 mm |
|---|
| Height | 27.5 mm |
|---|
Packaged Dimensions
| Packaged Dimensions | 2.6cm(Length) x 2.0cm(Width) x 4.0cm(Height) |
|---|
