3G-SDI TO DVI CONVERTER
- SDI signal conversion to DVI signal Auto-detects SD-SDI, HD-SDI and 3G-SDI input signals Operation at bitrates of 270Mbps, 1.485Gbps, 1.485/1.001Gbps, 2.970Gbps and 2.970/1.001Gbps Supports SDI standards of: - SMPTE 259M-C@270Mbps - SMPTE 292M@1.485Gbps and 1.485/1.001Gbps - SMPTE 424M and SMPTE 425M (Level A and Level B)@2.970Gbps and 2.970/1.001Gbps Converts SDI signals to the following DVI signals: - SD-SDI/SMPTE 259M-C to 480i and 576i - HD-SDI/SMPTE 292M to 720p and 1080i - 3G-SDI/SMPTE 424M and SMPTE 425M (Level A and Level B) to 1080p and 1080PsF Supports DVI output resolutions of: - 480i and 576i - 720p@50/59.94/60Hz and 1080i@50/59.94/60Hz - 1080p@23.98/24/25/29.97/30/50/59.94/60Hz - 1080PsF@23.98/24/25/29.97/30Hz Supports SDI input distance up to 300m (SD-SDI), 200m (HD-SDI) or 100m (3G-SDI)
