Very tough cable, specifically for the rigours of outdoor use in solar panel installations. Dust, age and UV resistant, tinned copper conductors to minimise corrosion. Use with our PV connectors for complete environmental protection.
Features:
• Insulation material: Double Layer XLPE
• TUV certified
• Commonly referred to as 6mm solar cable
Wire and Cable
| Wire Category | Solar system cable |
|---|
| Outer Diameter | 7.1 mm |
|---|
| Conductor Overall Diameter | 3.2 mm |
|---|
| Number of Conductor Strands | 81.0 pc |
|---|
| Individual Conductor Strand Diameter | 0.3 mm |
|---|
| Core Material | Tin Plated Copper |
|---|
| UV Resistant Cable | true |
|---|
| Resistance per Linear Metre | 3.52 mΩ |
|---|
| Retail Sales Unit | Metre |
|---|
| Roll Length | 100.0 m |
|---|
| Cross Sectional Area | 5.7 mm² |
|---|
Product colour
| Alternates available | false |
|---|
| Colour | Black |
|---|
Operating Temperature and Humidity
| Operating Temperature | -40.0°C-90.0°C |
|---|
DC Voltage Rating
DC Current Rating
Product Dimensions
| Cable length | 100.0 m |
|---|
| Diameter | 6.0 mm |
|---|
Packaged Dimensions
| Packaged Dimensions | 100.0cm(Length) x 0.6cm(Width) x 0.6cm(Height) |
|---|
