Perfect for the workshop as an an engine analyser as well as basic DMM. Full dwell angle measurement and tacho, with max / data hold and bright backlit LCD.
Features:
• Dwell angle
• RPM x10
• Data hold
• Max hold
• Continuity & diode test
• Backlight
• Auto power off
• Display: 2000 count
• Measurement Category: Cat II 1000V / Cat III 600V
• Diode Test
• Continuity Test
• Diode Test
• Continuity Test
Note: this unit is powered by 2x AAA batteries (included). The batteries are inserted into a plastic holder that goes into the battery compartment on the unit. Do not attempt to use a 9V battery with this unit.
Digital Multi-Meter
| Count Maximum Reading | 2.0 count |
|---|
Meter
| Meter Input Impedence | 10.0 MΩ |
|---|---|
| Measurement Range Count | 2.0 count |
Meter Display
| Display Type | LCD |
|---|---|
| Display Backlight | LED Backlit |
Power from disposable battery
| Size / Shape | AAA |
|---|---|
| Battery quantity | 2.0 pc |
Meter Safety Rating
| Safety Category | Cat III |
|---|---|
| Safety Rating Max Volt | 600.0 V |
Measures Voltage AC
| AC Voltage Ranges | 2.0V,20.0V,200.0V,700.0V |
|---|---|
| AC Voltage Accuracy | 1.0% % |
Measures Voltage DC
| DC Voltage Ranges | 200.0mV,2.0V,20.0V,200.0V,1.0V |
|---|---|
| DC Voltage Accuracy | 0.8% % |
Measures Current AC
| AC Current Ranges | 20.0mA,200.0mA,2.0A,10.0A |
|---|---|
| AC Current Accuracy | 1.8% % |
Measures Current DC
| DC Current Ranges | 20.0mA,200.0mA,2.0A,10.0A |
|---|---|
| DC Current Accuracy | 1.5% % |
Measures Resistance
| Resistance Ranges | 200.0Ω,2.0kΩ,20.0kΩ,200.0kΩ,2.0MΩ,20.0MΩ |
|---|---|
| Resistance Accuracy | 1.0% % |
Measures Temperature
| Outdoor / Exterior Scale | -20.0°C-1.0°C |
|---|---|
| Outdoor / Exterior Scale | -4.0°F-1.0°F |
Product Dimensions
| Length | 180.0 mm |
|---|---|
| Width | 87.0 mm |
| Depth | 50.0 mm |
Packaged Dimensions
| Packaged Dimensions | 22.4cm(Length) x 16.4cm(Width) x 6.2cm(Height) |
|---|
