Powercon Female Line 240V Mains Power Out 16A NAC3FXXB-W-S

Extra heavy duty Neutrik Powercon connector as used in commercial lighting and audio applications. Power Out version. NAC3FXXB-W-S. SAA approved. Specifications: Electrical Contact resistance: = 2 mΩ Dielectric strength: > 3 kVac (after mating cycles) Insulation resistance: > 10 GΩ (initially) Number of electrical contacts: 2 + PE Rating Europe: EN 60320-1: 16 A 250 V AC, CBC Rating USA / Canada: cUL 60320-1: 20 A 127 V AC, CBC Mechanical Cable O.D.: 6 - 12 mm Lifetime: typically 5’000 mating cycles Wiresize (mm²): 1.5 – 2.5 mm² Wiresize (AWG): 16 – 12 AWG, see above cable list Locking device: Twist lock Termination: Screw type terminals Material Contact plating: Ag Contacts: Copper Alloy Insert: Polyamide (PA6.6) Locking element: Zinc diecast Shell: Polyamide (PA6) / TPE Strain relief: Polyketone Bushing: Polypropylene / TPE Environmental Temperature range: -33 °C to + 80 °C Protection class: IP20 Flammability acc. to UL94: V-0 Features: Locking 240 V ac appliance coupler 3 contacts for line, neutral and premating safety ground Fast and easy twist lock latching system Extremely robust and reliable Ergonomic design User friendly latch design for easy handling Unique Neutrik chuck type strain relief When connecting to mains power this must be installed by a licensed electrician. To be installed in accordance to the latest issue of AS/NZ 3000 and by a licensed electrician as ruled in the state of installation.
