Powercon Male Chassis Plug 240V Mains 16A NAC3MPXXA

Extra heavy duty Neutrik Powercon connector as used in commercial lighting and audio applications. NAC3MPXXA. SAA approved. Specifications: Electrical Contact resistance: = 2 mΩ Dielectric strength: 4 kVdc / 2.8 kVac Insulation resistance: > 10 GΩ (initial) Number of electrical contacts: 2 + PE Rating Europe EN 60320-1: 16 A 250 V AC Rating USA UL 60320-1:20 A 127 V AC, UL 1977: 20 A 250 V AC Mechanical Lifetime: > 5000 mating cycles Wiresize: 2,5 mm² Wiresize: 12 AWG Material Contact plating: Ag Locking element: Stainless steel Shell: Polyamide (PA 6.6) Contacts: Copper Alloy Environmental Flammability: UL 94 V-0 Protection class: IP 20 Temperature range: -30 °C to +80 °C Features: Locking 250 V ac appliance coupler 3 contacts for line, neutral and premating safety ground Fast and easy twist lock latching system Extremely robust and reliable Ergonomic design User friendly latch design for easy handling When connecting to mains power this must be installed by a licensed electrician. To be installed in accordance to the latest issue of AS/NZ 3000 and by a licensed electrician as ruled in the state of installation.
