All speakers in this range are equipped with titanium coated fibre woofers and silk dome tweeters for smooth high frequency response.
Sold as a pair.
Speaker Specifications
| Sold as a Pair | true |
|---|
| Speaker Type | woofer |
|---|
| Nominal Impedance | 4.0 Ω |
|---|
| RMS Power Rating | 15.0 W |
|---|
| Resonant Frequency | 130.0 Hz |
|---|
| Sensitivity (SPL@1W, 1m) | 84.0 |
|---|
| Mechanical Q (Q<sub>ms</sub>) | 3.09 |
|---|
| Electrical Q Factor (Q<sub>es</sub>) | 1.9 |
|---|
| Total Q (Q<sub>ts</sub>) | 1.18 |
|---|
| Equivalent Volume (V<sub>as</sub>) | 1.48 l |
|---|
| Side-to-Side Diameter (A) | 102.0 mm |
|---|
| Mounting Hole Diameter (B) | 115.0 mm |
|---|
| Cutout Diameter (C) | 93.0 mm |
|---|
| Insert Depth (D) | 42.0 mm |
|---|
Product Dimensions
| Height | 49.0 mm |
|---|
| Diameter | 102.0 mm |
|---|
Packaged Dimensions
| Packaged Dimensions | 29.3cm(Length) x 15.4cm(Width) x 9.1cm(Height) |
|---|
