All speakers in this range are equipped with titanium coated fibre woofers and silk dome tweeters for smooth high frequency response.
Sold as a pair.
Speaker Specifications
| Sold as a Pair | true |
|---|
| Speaker Type | woofer |
|---|
| Nominal Impedance | 4.0 Ω |
|---|
| RMS Power Rating | 22.0 W |
|---|
| Resonant Frequency | 73.0 Hz |
|---|
| Sensitivity (SPL@1W, 1m) | 88.0 |
|---|
| Mechanical Q (Q<sub>ms</sub>) | 3.85 |
|---|
| Electrical Q Factor (Q<sub>es</sub>) | 1.25 |
|---|
| Total Q (Q<sub>ts</sub>) | 0.94 |
|---|
| Equivalent Volume (V<sub>as</sub>) | 13.4 l |
|---|
| Side-to-Side Diameter (A) | 165.0 mm |
|---|
| Mounting Hole Diameter (B) | 158.0 mm |
|---|
| Cutout Diameter (C) | 142.0 mm |
|---|
| Insert Depth (D) | 58.0 mm |
|---|
Product Dimensions
| Height | 62.0 mm |
|---|
| Diameter | 165.0 mm |
|---|
Packaged Dimensions
| Packaged Dimensions | 35.0cm(Length) x 19.7cm(Width) x 10.0cm(Height) |
|---|
